C1-USTS // Technical Data

description: LED spotlight for installation on magnetic track
180° rotatable, 90° swivelled
housing colour: aluminium anodised black, silver, gold
(other surface finishing on request)
LED-type: high power LED, high CRI
lifetime: 50,000 hours
basis of lifetime: L70B10
compliant to EMC: DIN EN 55015:2013
light colour (+/- 100K): ~2,700K, ~3,000K, ~4,000K, ~5,700K
max. luminous flux: ~130lm
max. power consumption: ~2.5W
LED driver: internal
power input: 12V DC constant voltage
dimming: external
protection class: IP 20
allowed power supplies: power supply for the LPF, LPV, NPF or APV by MeanWell
with constant voltage 12V DC, class 2
in combination with a feno dimmer
(other power supplies on request)
accessory: magnetic track (11 x 7 mm), holders
additional accessory:
  • lenses: 10°, 15°, 20°, 35°, 45° and 46°+ 10°
  • honeycomb grid, anti-glare tube, inclined tube, light diffusion foil, barn door
  • zoom optic
